CNC Milling Drilling Tapping Machine

Name: JD40W-GS rail speed milling compound lathe

Detailed introduction
 Features of JD40W-GS rail speed milling compound lathe:
 The permanent stability and high rigidity of the machine are guaranteed by using resin sand process cast iron.
 It has high speed, high precision and reliable performance, which can be used to process the plate and short axis products.
 The line rail is used in the line rail, which can be used for heavy cutting.
 According to the selection of 1-6 knife-position servo power head, can be integrated into car, milling, drilling, boring, tapping and other functional compound processing, which can ensure product precision and improve efficiency.
 The machine is designed for humanization, with beautiful appearance and easy operation.



JD40W-GS Main technical parameters of wire rail high speed turning milling compound lathe
Project content	Company	parameter
Maximum revolution diameter  of bed	mm	φ470
Maximum revolution diameter  of excess carriage	mm	φ270
Maximum top margin	mm	430
Maximum Z-axle stroke	mm	370
Maximum X-axle stroke	mm	370
Rapid travel speed	mm/min	X:12  Z:18
Diameter of spindle through hole	mm	φ48
Power of main motor	kw	3.7 servo main motor /4.0 frequency conversion main motor
Rotation speed of spindle	r/min	20-5000
Sectional ayea of cutter arbor	mm	20X20
Stroke of tailstock sleeve	mm	140
Taper of sleeve bore	mt	NO.4
Chuck specification	mm	φ160/φ200
Positioning accuracy	mm	X:0.01  Z:0.01
Pulse equivalent	mm	X:0.0005  Z:0.001
Cooling water pump	w	90
Weight of machine tool	kg	≈1800
Contour dimension of machine tool （LxWxH））	mm	≈2200X1650X1680

JD40W-GS Wire rail high speed turning milling compound lathe standard and selection function
Beijing KND CNC system	S
AC Servo system	S
The spring clamp with solid rotary oil cylinder,hydraulic station	S
Tool carriage	S
3.7KW/5.5KW servo motor （spindle unit）	S
Stepless speed regulation spindle	S
Automatic lubrication	S
Hydraulic tailstock	S
Thread function of Metric/British standard	S/
Cooling system	S/
Csn increase the Y axis be in progress Driling,miling,lathe combined machining	O
S： Standard  O： Select  /： Not Select

Product Details



Shipping and packing



Our service

Before sales
 Our professional technical recommend the right machine,and can also customise special machine as customer's requirement and special parts.
Sales following
 During machine production, watching the machine quality and testing machine.and take pictures or make video for customer checking.
After Sales
 We will send technical go to customer's factory to install and adjust machine.
 We have after-sell service to supply all life-time machine maintance and repairment service.



FAQ:

 Q:How do I get a quotation?
 A:Let us design according to your purchase request, we will reply you as soon as possible, and you can contact us directly by phone or email.
 Q:Can you provide a customized machine?
 A:Yes, our company can be customized according to customer's requirements
 Q:Can you provide training for operating machines?
 A:Yes, our factory has free training
